3S/4S/5S 100A Polymer/Lithium Iron Phosphate Battery Protection Circuit Board US

Description

Store Categories Store Categories Other Product View Details 3S 100A Polymer Overcharge protection current: 100A Over-discharge protection current: 100A Over-discharge protection delay: 0.5-1.5S Contact discharge current: 80A Synopline discharge current: 60A Charge current: 60A Ampere balance (current): 60MA Current balance accuracy: 4.14-4.24V 4S 100A 3.7V polymer Over-discharge protection current:100A Charge Current (Continuous):60A Split port discharge current (continuous):80A (Max) Same port discharge current ((continuous): 60A(Max)) Static current: 25uA Voltage: 3.7V (3.7V can only be used with lithium ternary batteries, not lithium iron phosphate) Overcurrent protection recovery mode: disconnect the load release Equalization function: Yes Equalization voltage: 4.18v Equalization current: 60mA Body size: 62*42*4mm Operating Temperature: -20℃~65 Storage Temperature: -40°C~85°C 5S 100A 3.7V Polymer Number of strings:5S Over-discharge protection current:100A Charging Current(Continuous):60A Split port discharge current (continuous): 80A (Max) Same port discharge current ((continuous): 60A(Max)) Static current: 25uA Voltage: 3.7V (3.7V can only be used with lithium ternary batteries, not lithium iron phosphate) Overcurrent protection recovery mode: disconnect the load release Equalization function: Yes Equalization voltage: 4.18v Equalization current: 60mA Body size: 62*42*4mm Operating Temperature: -20℃~65 Storage Temperature: -40°C~85°C 18V 100A 5S Lithium iron phosphate Lithium iron phosphate Voltage: 3.2 V Current: 100A Overcharge protection delay: 1.5-2.5S Single battery over-discharge protection voltage: 2.27-2.43 V. Single-cell battery over-discharge protection recovery voltage: 2.45-2.65 V. Overcharge protection current: 100A Over-discharge protection current: 100A Over-discharge protection delay: 0.5-1.5S Temperature protection: Yes Disconnection protection: Yes Shortage protection: Yes Shortage delay: 100-600 Shortage protection recovery: Disconnect Charging current: 60A Amp balance (current): 50MA Voltage Accuracy: 3.355-3.455 V. Charging Voltage: 3.2V * 5 = 16V 3S/4S/5S 100A 3.2V Lithium Iron Phosphate Pinout method: P-: load negative C-: charger negative B-: battery negative Practical guide Output current: 80A for split port; 60A for same port Note: Lithium batteries should be charged with a special charger for lithium batteries, do not use a lead-acid battery charger, lead-acid charging may have a high-voltage breakdown of the protection board MOS tubes, resulting in the protection board overcharge is not protected. (1) 3-series split port wiring method (refer to 3-series split port wiring diagram) ① Connect the 3 battery packs in series according to the connection method of the batteries in the 3-series split port wiring diagram. ② Connect the negative terminal of the charger to C- of the protection board and the negative terminal of the load to P-. ③ Connect the positive terminals of the charger and load to the positive terminals of the 3 series batteries. ④ Referring to the wiring diagram of the 3-series split port, use 3 wires to connect the positive terminals of the 3 battery packs to B+, B4, and B3 respectively in sequence. ⑤ Connect the negative terminals of the 3 battery packs to B-. B1, B2 and B- are shorted. ⑥All wires should be connected according to the wiring diagram of the 3 serial ports and checked to make sure they are correct before use. ⑦When the indicator light on the protection board is on during use, it means that the corresponding battery pack is in a balanced working state (i.e., the battery is not balanced at this time). 3S/4S/5S 100A lithium iron phosphate 3S/4S/5S 100A polymer lithium ternary Lithium iron phosphate protection board parameters: Overcharge Voltage: Minimum 3.61V, Typical 3.65V, Maximum 3.69V Overcharge recovery voltage: Minimum 3.5V, Typical 3.55V, Maximum 3.6V Over-charging voltage protection delay: 500mS minimum, 1000mS typical, 1500mS max. Over-discharge voltage: min. 2.27V, typical 2.35V, max. 2.43V Over-discharge recovery voltage: min. 2.45V, typical 2.55V, max. 2.65V Over-amplified voltage protection delay time: minimum 500mS, typical value 1000mS, maximum value 1500mS Over-discharge protection current: 100A Split discharge current (continuous): 50A (max. 80A) Same port discharge current (continuous): 40A (max. 60A) Over-discharge current protection delay: minimum 100mS, typical 200mS, maximum 300mS Overcharge protection current: 100A Charging current (continuous):40A (max. 60A) Overcharge current protection delay: 10mS minimum, 20mS typical, 30mS maximum Quiescent current:17μA (max 25μA) Temperature protection: with temperature control interface Disconnection protection: Yes Short circuit protection: Yes Short-circuit delay time: minimum 100μS, typical 300μS, maximum 600μS Overcurrent protection recovery mode: disconnect the load release Equalization function: Yes Equalization voltage: 3.405v Equalization current: 60mA Body Size: 62*42*4mm Color: white (PCB) Standard accessories: circuit board Operating Temperature: -20℃~+65℃ Storage temperature：-40℃~+85℃ Polymer lithium ternary protection board parameters: Overcharge Voltage: Minimum 4.21V, Typical 4.25V, Maximum 4.29V Overcharge recovery voltage: Minimum 4.14V, Typical 4.19V, Maximum 4.24V Over-charging voltage protection delay time: minimum 500mS, typical value 1000mS, maximum value 1500mS Over-discharge voltage: min. 2.72V, typical 2.8V, max. 2.88V Over-discharge recovery voltage: min. 2.9V, typical value 3V, max. 3.1V Over-amplified voltage protection delay time: minimum 500mS, typical value 1000mS, maximum value 1500mS Over-discharge protection current: 100A Split discharge current (continuous): 50A (max. 80A) Same port discharge current (continuous): 40A (max. 60A) Over-discharge current protection delay: minimum 100mS, typical 200mS, maximum 300mS Overcharge protection current: 100A Charging current (continuous):40A (max. 60A) Overcharge current protection delay: 10mS minimum, 20mS typical, 30mS maximum Quiescent current:17μA (max 25μA) Temperature protection: with temperature control interface Disconnection protection: Yes Short circuit protection: Yes Short-circuit delay time: minimum 100μS, typical 300μS, maximum 600μS Overcurrent protection recovery mode: disconnect the load release Equalization function: Yes Equalization voltage: 4.18v Equalization current: 60mA Body Size: 62*42*4mm Color: white (PCB) Standard accessories: circuit board Operating Temperature: -20℃~+65℃ Storage temperature：-40℃~+85℃ Shipping Policy Payment Method Returns Policy Shipping Policy Payment Method Returns Policy Home Payment Shipping About us Contact us Copyright©2018 datacaciques Home Payment Shipping About us Contact us Store Categories Store Categories Other Product View Details 3S 100A Polymer Overcharge protection current: 100A Over-discharge protection current: 100A Over-discharge protection delay: 0.5-1.5S Contact discharge current: 80A Synopline discharge current: 60A Charge current: 60A Ampere balance (current): 60MA Current balance accuracy: 4.14-4.24V 4S 100A 3.7V polymer Over-discharge protection current:100A Charge Current (Continuous):60A Split port discharge current (continuous):80A (Max) Same port discharge current ((continuous): 60A(Max)) Static current: 25uA Voltage: 3.7V (3.7V can only be used with lithium ternary batteries, not lithium iron phosphate) Overcurrent protection recovery mode: disconnect the load release Equalization function: Yes Equalization voltage: 4.18v Equalization current: 60mA Body size: 62*42*4mm Operating Temperature: -20℃~65 Storage Temperature: -40°C~85°C 5S 100A 3.7V Polymer Number of strings:5S Over-discharge protection current:100A Charging Current(Continuous):60A Split port discharge current (continuous): 80A (Max) Same port discharge current ((continuous): 60A(Max)) Static current: 25uA Voltage: 3.7V (3.7V can only be used with lithium ternary batteries, not lithium iron phosphate) Overcurrent protection recovery mode: disconnect the load release Equalization function: Yes Equalization voltage: 4.18v Equalization current: 60mA Body size: 62*42*4mm Operating Temperature: -20℃~65 Storage Temperature: -40°C~85°C 18V 100A 5S Lithium iron phosphate Lithium iron phosphate Voltage: 3.2 V Current: 100A Overcharge protection delay: 1.5-2.5S Single battery over-discharge protection voltage: 2.27-2.43 V. Single-cell battery over-discharge protection recovery voltage: 2.45-2.65 V. Overcharge protection current: 100A Over-discharge protection current: 100A Over-discharge protection delay: 0.5-1.5S Temperature protection: Yes Disconnection protection: Yes Shortage protection: Yes Shortage delay: 100-600 Shortage protection recovery: Disconnect Charging current: 60A Amp balance (current): 50MA Voltage Accuracy: 3.355-3.455 V. Charging Voltage: 3.2V * 5 = 16V 3S/4S/5S 100A 3.2V Lithium Iron Phosphate Pinout method: P-: load negative C-: charger negative B-: battery negative Practical guide Output current: 80A for split port; 60A for same port Note: Lithium batteries should be charged with a special charger for lithium batteries, do not use a lead-acid battery charger, lead-acid charging may have a high-voltage breakdown of the protection board MOS tubes, resulting in the protection board overcharge is not protected. (1) 3-series split port wiring method (refer to 3-series split port wiring diagram) ① Connect the 3 battery packs in series according to the connection method of the batteries in the 3-series split port wiring diagram. ② Connect the negative terminal of the charger to C- of the protection board and the negative terminal of the load to P-. ③ Connect the positive terminals of the charger and load to the positive terminals of the 3 series batteries. ④ Referring to the wiring diagram of the 3-series split port, use 3 wires to connect the positive terminals of the 3 battery packs to B+, B4, and B3 respectively in sequence. ⑤ Connect the negative terminals of the 3 battery packs to B-. B1, B2 and B- are shorted. ⑥All wires should be connected according to the wiring diagram of the 3 serial ports and checked to make sure they are correct before use. ⑦When the indicator light on the protection board is on during use, it means that the corresponding battery pack is in a balanced working state (i.e., the battery is not balanced at this time). 3S/4S/5S 100A lithium iron phosphate 3S/4S/5S 100A polymer lithium ternary Lithium iron phosphate protection board parameters: Overcharge Voltage: Minimum 3.61V, Typical 3.65V, Maximum 3.69V Overcharge recovery voltage: Minimum 3.5V, Typical 3.55V, Maximum 3.6V Over-charging voltage protection delay: 500mS minimum, 1000mS typical, 1500mS max. Over-discharge voltage: min. 2.27V, typical 2.35V, max. 2.43V Over-discharge recovery voltage: min. 2.45V, typical 2.55V, max. 2.65V Over-amplified voltage protection delay time: minimum 500mS, typical value 1000mS, maximum value 1500mS Over-discharge protection current: 100A Split discharge current (continuous): 50A (max. 80A) Same port discharge current (continuous): 40A (max. 60A) Over-discharge current protection delay: minimum 100mS, typical 200mS, maximum 300mS Overcharge protection current: 100A Charging current (continuous):40A (max. 60A) Overcharge current protection delay: 10mS minimum, 20mS typical, 30mS maximum Quiescent current:17μA (max 25μA) Temperature protection: with temperature control interface Disconnection protection: Yes Short circuit protection: Yes Short-circuit delay time: minimum 100μS, typical 300μS, maximum 600μS Overcurrent protection recovery mode: disconnect the load release Equalization function: Yes Equalization voltage: 3.405v Equalization current: 60mA Body Size: 62*42*4mm Color: white (PCB) Standard accessories: circuit board Operating Temperature: -20℃~+65℃ Storage temperature：-40℃~+85℃ Polymer lithium ternary protection board parameters: Overcharge Voltage: Minimum 4.21V, Typical 4.25V, Maximum 4.29V Overcharge recovery voltage: Minimum 4.14V, Typical 4.19V, Maximum 4.24V Over-charging voltage protection delay time: minimum 500mS, typical value 1000mS, maximum value 1500mS Over-discharge voltage: min. 2.72V, typical 2.8V, max. 2.88V Over-discharge recovery voltage: min. 2.9V, typical value 3V, max. 3.1V Over-amplified voltage protection delay time: minimum 500mS, typical value 1000mS, maximum value 1500mS Over-discharge protection current: 100A Split discharge current (continuous): 50A (max. 80A) Same port discharge current (continuous): 40A (max. 60A) Over-discharge current protection delay: minimum 100mS, typical 200mS, maximum 300mS Overcharge protection current: 100A Charging current (continuous):40A (max. 60A) Overcharge current protection delay: 10mS minimum, 20mS typical, 30mS maximum Quiescent current:17μA (max 25μA) Temperature protection: with temperature control interface Disconnection protection: Yes Short circuit protection: Yes Short-circuit delay time: minimum 100μS, typical 300μS, maximum 600μS Overcurrent protection recovery mode: disconnect the load release Equalization function: Yes Equalization voltage: 4.18v Equalization current: 60mA Body Size: 62*42*4mm Color: white (PCB) Standard accessories: circuit board Operating Temperature: -20℃~+65℃ Storage temperature：-40℃~+85℃ Shipping Policy Payment Method Returns Policy Shipping Policy We will arrange shipping for you within 24 Hours after payment cleared except the holidays. -We ship items to Worldwide. Thank you! -we will ship out the order in 1-2 business days after payment cleared .Since it is international shipping ,delivery time is about 15--28 business days to arrive to most countries. Payment Method We accept PayPal payment ONLY, and must be received within 5 days from the date of purchase. 2. It is easy and safe for you to pay by credit cards, debit cards, bank transfers and PayPal account balances. 3.Buyers are responsible for import duties,custom fees and taxes, if any, please check your country. Returns Policy 1.We believe our items are so outstanding. We are convinced you will be happy with your Purchase. 2. If you do not satisfy with our items. Please simply return to us within 30 Days in original condition. Just pay for the returned postage. Then we can issue full refund or resend the item to you after the returned item arrived at our warehouse. 3. Please include your eBay ID and item number with any email requests.
