4K IP CCTV Tester with AHD CVI TVI WiFi POE DMM OPM

Description

Welcome to Rsrten g, I f yo u hav e any questions pl ease feel free to contact us.Thanks! Note: This is a professional multifunctional ca mera tester used in Industry and Business. It may be relatively complicated during operation. If you need any technical support, you can contact us at any time, and we will provide you with service at any time. Main Features : 【5-in-1 Design】--The A86 is a versatile 5-in-1 tester. Support network test, IPC test, TDR network line breakpoint test, PTZ control test, analog, coaxial HD test, HDMI signal monitoring, wireless test. Apply to equipment installation, equipment commissioning, troubleshooting and maintenance for security engineering. 【Powerful data analysis capabilities】--The A86 captures time-period data and event waveform screenshots to help identify the root cause of device and line problems. Help users solve the most difficult intermittent events, easy for technicians to view and analyze. 【 WI FI tes t 】--Built-in wireless WIFI function, can test wireless network camera, support the creation of WIFI hotspot, WIFI and LAN connection. Support 2.4G, 5G frequency band, spectrum test, signal strength test. Support HD-CVI 8MP/ TVI 8MP/ AHD 5MP highest resolution image test, coaxial video control and OSD menu call, support photo, video, zoom, playback, easy engineering acceptance. 【 Dual battery 】--Dual battery compartments. Each battery compartment can hold a dedicated lithium battery pack with a capacity of 18.5Wh. The combined working time is about 10 hours. ( can operate on a single battery ) . 【More features】--Simultaneous support for analog SD, analog HD, network HD monitoring systems. Dual 1000M network interfaces, and can detect packet loss, data traffic, and so on. External foldable dual antenna, dual frequency Dipole omnidirectional antenna. Specification: System parameters Display screen 7.0 inch capacitive Multi-touch screen, full-fit technology. 1920x1200 resolution, color 16.7M, Backlight brightness adjustable Keyboard Silicone buttons with 14 keys, comfortable feel Operating system Linux System update Support online update Language English, 中文 , Español, Français, Deutsch, Türkçe, Русский, Italiano, 한국어 , Polski Automatic standby Disable / 5 to 60 minutes Keyboard tone Enabled / Disable IP Camera test IPC protocol O-N-V-I-F, RTSP, RTP Ethernet test 10/100/1000Mbps Ethernet link detection; Ethernet loop detection; DHCP client and server; Ethernet traffic detection, data link quality detection. IP Camera test Discovering the device, real-time video, camera configuration, PTZ test, discovering ON-VIF device cross the network segment. IP Camera image test support 4K 8MP / 30fps, local zoom preview at 8 levels. Interface Dual RJ45 Ethernet interface, 10/100/1000Mbps adaptive. support serial connection; WI-FI test WIFI test Support 2.4GHz and 5GHz frequency band, WIFI connection, WIFI list, WIFI information detection, delay detection, test of packet loss rate. Spectrum test Support 2.4GHz and 5GHz frequency band, spatial frequency band signal scanning and detection, and spatial noise (interference) signal detection. Signal monitoring Support 2.4G and 5G frequency band quick monitoring of signal change, refresh frequency: 1 to 10Hz. Antenna type External foldable dual antenna. Dual band Dipole omnidirectional antenna POE test PD test The tester receives the power. IEEE802.3at; power supply voltage detection PSE test The tester supplies the POE power. IEEE802.3at, max 25.5W, PD actual power detection Coaxial HD and SD video test Video format (NTSC/PAL) HD-CVI: 720p@25/30/50/60fps, 1080p@25/30fps, 2560×1440@25/30fps, 2880×1620@25/30fps, 3840×2160@12.5/15fps HD-TVI: 720p@25/30/50/60 fps, 1080p@25/30fps, 2048×1536@18 fps, 2560×1440@25/30 fps, 3840×2160@15fps AHD: 720p@25/30fps, 1080p@25/30fps, 2048×1536@18/25/30fps, 2560×1440@25/, 3840×2160@15fps CVBS Video signal 1Vpp Video input /output BNC input / BNC output Video digital zoom Support the zoom at 8 levels Video signal generator (color bar test) Sending PAL/NTSC, CVI/AHD/TVI video test signal, 720P/1080P. HDMI signal test HDMI Input Support 720P 25/30/50/60fps, 1080P 25/30/50/60fps input signals for display HDMI Output Support output test images 720P 50/60fps, 1080P 25/30/50/60fps to external screen 12V power output Power output 1x 12V/2A output Interface on tester 1x 12V/1A output Interface on each battery (Each battery has an independent power output interface, which can directly output DC12V/1A power) Audio test Audio test 1 x Audio signal input Coaxial PTZ control test Communication interface Video BNC input interface Communication protocol CVI protocol (for Dahua coax), AHD protocol (Pelco c), TVI protocol(for Hikvision coax) RS485 PTZ control test Communication interface RS485 Communication protocol More than 30 protocols, including for Pelco-D/P, Samsung, Panasonic, Lilin and Yaan Baud rate 150/300/600/1,200/2,400/4,800/9,600 and 19,200bps LED lighting(flashlight) Head LED 2 x 35lm LED, wide angel RJ45 TDR cable test RJ45 Cable test Testing the length of RJ45 network cable (4 pairs). Resolution: 0.1 meter; Accuracy: 1 meter. The max length of the measured cable is 130 to 200m (426ft to 656ft) (depending on the wire rod). Power supply Charger 12V/1.5A power supply, charging time: 3 to 4 hours. Battery 2x DC7.4V/2500mAh, 18.5Wh Li-ion battery Tester equipped with two battery compartments. Both the installation of a single battery or installation of 2 batteries can work normally, and the combined working time of the two batteries is about 5 to 10 hours. The battery has an independent charging and power supply interface. It can be charged separately or power the camera. Power saving function Can set the automatic switching of overtime and display the icon of battery level in real-time. Working environment and specifications Working temperature -10 ℃ to +55 ℃ (14 ℉ to 131 ℉ ) Working humidity 30%~90%(RH) Device dimension 235x135x45mm(9.25x5.31x1.77inch) Packed/Net weight 2.2KG (4.85lbs)/0.93kg(2.05lb) Digital Multi-meter (only A86 support, A82 don’t support) Measuring type Measuring range Range of readings Minimum resolution Accuracy DC voltage (DCV) 2V, 20V, 200V, 600V ±19999 0.1mV ±0.1%+8 * AC voltage (ACV) ( True RMS) 20V , 200V , 600V ±1999 1V ±1.2%+3 DC current 20mA, 200mA, 2000mA ±19999 1uA ±0.1%+8 * AC current ( True RMS) 20mA, 200mA, 2000mA ±1999 1uA ±1.2%+3 Resistor 2K Ω , 20K Ω , 200K Ω , 2MΩ, 20MΩ 0~19999 0.1Ω ±0.1%+8 * Capacitance 2nF, 20nF, 200nF, 2uF, 20uF, 200uF, 2mF, 20mF 0~1999 1pF ±4%+5 Diode forward voltage drop 2V 0~19999 0.1mV ±0.1%+20 ON/OFF test 2KΩ 0~19999 0.1Ω ±0.1%+20 Laser power meter (only A86 support, A82 don’t support) Type of detector InGaAs Calibration wavelength 1625nm, 1550nm,1480nm,1310nm,1300nm, 850nm Power measurement range (dBm) -70 to +10 dBm Measurement accuracy <±0.3dB (-10dBm/22 ℃ ) <±0.5dB (Full-scale range/22 ℃ ) Display resolution Linear display:0.1%, Logarighmic display: 0.01dBm Connector Movable FC/PC
