7-40V to 1.2-35V 8A 300W Buck Converter Step-down Power Module CC CV

Description

Description: Module nature: non-isolated step-down constant current, constant voltage module (CC CV) charging module Scope of ap plication: high-power LED constant current drive, lithium battery charging (including ferroelectric), 4V, 6V, 12V, 14V, 24V battery charging, nickel-cadmium-nickel-metal hydride battery (battery pack) charging, solar panel, wind generator. Input voltage: 7-40V Output voltage: 1.2-35V (continuously adjustable) Output current: Max. 8A (please add a fan to cool the power tube if the temperature exceeds 65 ° C, within 24V to 12V and 6A, you can generally leave the fan in an open environment) Constant current range: 0.2-8A (adjustable) Turn current: constant current value * (0.1), the turn current and constant current value are linked, for example, the constant current value is 3A, the turn current is set to 0.1 times the constant current (0.1 * 3A = 0.3A). When the current value is adjusted to 2A, the current of the turn lamp is 0.1 times of the constant current (0.1 * 2A = 0.2A). This version is fixed at 0.1 times (the actual turn lamp current is approximate and not very accurate). It is used to indicate whether the battery is fully charged. Lowest dropout: 1V Output power: The maximum power is about 300W. If the temperature of the power tube exceeds 65 degrees, please add a fan. Conversion efficiency: up to about 95% (the higher the output voltage, the higher the efficiency) Working frequency: 180KHZ Output ripple: 20M bandwidth (for reference only) Input 24V output 12V 5A ripple about 50mV (excluding noise) (please pay attention to the temperature of the power tube in actual use, please strengthen heat dissipation if the temperature is too high) No-load current: 20mA typical (24V to 12V) Load adjustment rate: ± 1% (constant voltage) Voltage adjustment rate: ± 1% Constant current accuracy and temperature: The actual test, the temperature on the module changes from 25 degrees to 60 degrees, and the constant current value changes less than 5% (constant current value 5A) Dynamic response speed: 5% 200uS Potentiometer adjustment direction: clockwise (increase), counterclockwise (decrease) Close to the input potentiometer for voltage adjustment (CV), and close to the output potentiometer for current adjustment (CC) Indicators: two-color indicator, red indicator during charging, green indicator after charging (green without load), indicator without constant current is red. Output short circuit protection: Yes, constant current (current value of constant current setting) Input reverse connection protection: None. Output prevents backflow: None. Wiring method: terminal Size: 65 (length) * 47 (width) * 23.5 (height) mm Weight: 20G Application: Adjustable power supply, high-power LED driver, LED display driver, lead-acid battery charging, lithium battery charging, car power supply, car notebook power supply (step-down), regulated power supply, low-voltage system power supply, (eg 12V battery for children's toy cars Pressure to 6V), 24V to 12V 12V to 5V24V to 5V24V to 19V 20V and so on. Battery charging method: 1. Determine the floating voltage and charging current of the battery you need to charge, and the input voltage of the module; 2. Adjust the constant voltage positioner to adjust the output voltage to about 5V. 3. Measure the output short-circuit current with the multimeter 10A current block, and adjust the constant current potentiometer to make the output current reach the predetermined charging current value; 4. Adjust the constant voltage positioner to make the output voltage reach the floating charge voltage; 5. Connect the battery and try charging. (Steps 1, 2, 3, and 4 connect the module input to the power supply, and the output is not connected to the battery.) LED constant current drive 1. Determine the working current and maximum working voltage you need to drive the LED; 2. Adjust the constant voltage positioner to adjust the output voltage to about 5V. 3. Use a multimeter 10A current block to measure the output short-circuit current, and at the same time adjust the constant current potentiometer to make the output current reach the predetermined LED working current; 4. Adjust the constant voltage positioner so that the output voltage reaches the maximum LED operating voltage; 5. Connect the LED and test the machine. (Steps 1, 2, 3, and 4 connect the module input to the power supply, and the output is not connected to the LED light.) Note: Please allow minor errors due to manual measurement. Item color displayed in photos may be showing slightly different since monitors are not calibrated same. Package Contents: 1pc of Power Module Payment: We only accept PayPal . PayPal is the only online payment method we accept. Please make sure you have a valid/confirmed PayPal account prior bidding. And please make sure that your PayPal registed address is the same with your eBay registed address. Shipping: It usually takes about 10-30 working days to arrive for economy shipping which not including tracking number; 7-15 working days for standard shipping which including tracking number. Transit time may be a little delayed because of the bad weather and customs inspection. If you do not receive your item within 30 working days since payment finished, please contact us immediately for further assistance. Note: It may takes more than 30 working days to other countries such as Mexico,Brazil,Chile,Peru, because they is far away from China. PS: We also offer faster shipping service (3-5 days to deliver), such as DHL,EMS, but buyers need to pay for the extra shipping cost. Please contact us if you need it. Customs Declaration: Import duties, taxes and charges are not included in the item price or shipping charges. These charges are the buyer's responsibility. Please check with your country's customs office to determine what these additional costs will be prior to bidding. Return Policy: If you are dissatisfied with our item or service, then please follow the good eBay practice to contact us by eBay message before leaving any feedback. We are committed to resolve all issues in a friendly and satisfactory manner. We always reply to eBay messages within 1-2 business days. If you do not get a response from us, then please check your eBay message. Only unused, undamaged and original condition item can be qualified for a return. Feedback: We strive for 100% customer satisfaction! Positive Feedback is very important to us. If you have any questions, please feel free to contact us instead of leaving negative feedback. We will reply your email within 24 working hours.
