SARK100 ANT SWR Antenna Analyzer Meter 1-60M

Description

SARK100 ANT SWR Antenna Analyzer Meter 1-60M Features: - This is a SWR Analyzer for ham hobbists. - User manual is to be sent by email upon request. - Frequency Generation & Control: 1 - 60 Mhz - Source impedance: 50 Ohms - Stability: +/- 100 ppm - Spectral Purity: Harmonics down >- TBD dB beyond 60 MHz - Step Size: User configurable increments of 100 Hz, 1 kHz, 10 kHz, and 100 kHz - Usable Measurement Range:SWR: 1.0 to 9.99 - Impedance: approx. 5 to 2000 ohms - RF Output: Adjustable: 2.0 Volts pp (typ) - Power supply: Powerd by External: 12 to 15 Volts DC, 500mA - Controls: Pushbuttons (5): "Mode", "Band", "Config", "Scan", "Up", "Down" - Switch: "Power On" - USB: Mini-B receptacle - External power: 2.1mm Power Jack (center pin positive) Applications: - Measure antenna electrical parameters: SWR, impedance (resistance + reactance), capacitance, inductance - Measure feedpoint impedance - Measure ground loss - Adjust antenna tuners and determine loss - Measure inductors and capacitors - Measure coax transmission line (SWR, length, velocity factor, approximate Q and loss, resonant frequency, and impedance) - Measure and determine optimum settings for tuning stubs: SWR, approximate - Q, resonant frequency, bandwidth, impedance - Determine characteristic impedance of transmission line - Determine length of and wave phasing lines - Coaxial Cable Loss - Determine antenna tuner loss - Measure balun loss - Measure inductor Q - Estimate quartz crystal parameters - Measure magnetic loop resonance and SWR - Operation button definitions: - Mode: selects operation mode: impedance(default), complex impedance, capacitance, and inducatance - BAND: select band from any of the available bands: 160M to 6M - CONFIG: Provides menu for configurations and extended functions: PC Link, step size setting, suspend timeout setting, calibration, and software upgrade - SCAN: pressing this control initiates a scan of frequencies of the selected BAND. Scan exits to impedance mode showing the 2:1 bandwidth and the resonant point o the antenna - CAN(up): increase frequency and used to cancel operation for CONFIG menu - VAL(down): decrease frequency and used to validate operation for CONFIG menu Package including： - 1PCS SWR Analyzer & Assembled ready for use * ANTENNA HAM RADIO HOBBIST Notice: Because,the international air shipping forbid to ship liquid,powder and batteries, If you purchased goods containing such items, we will not be putting them packing. Thank you for your support. Shipping Please read this before buying International Shipping may Be Delayed Due to Customs. Customers are Responsible For All Import Charges, Tariffs, Duties, Taxes, and Fees Associated with Import of the product. Shipping Charges does not include any Import Charges, Tariffs, Duties, Taxes, and Fees Associated with it. We are not responsible for undeliverable address.We reserve the right to charge the shipping fee again for returned items due to wrong address. Items are generally shipped within 10 business day after your payment has been cleared (Sat. & Sun. excluded.) Contact us Please contact us with any comments, questions or suggestions that you may have bysending ebay message, All the mail will be replied within 24 hours.
